Soundbar Specifications

General Specifications

• Power Supply: 100–240V AC, 50/60Hz
• Operating Temperature: 0°C to 45°C

Audio Performance

• Total Maximum Output Power: 300W
• Soundbar Output Power: 2 × 50W
• Subwoofer Output Power: 200W
• Frequency Response: 40Hz–20kHz
• Soundbar Drivers: 4 × racetrack drivers and 2 × 1-inch tweeters
• Subwoofer Driver: 6.5-inch
• Standby Power Consumption: Less than 0.5W

Connectivity

• Audio Inputs: Optical, Bluetooth, USB*
• USB Port: Type-A
• USB Power Rating: 5V DC / 0.5A
• Bluetooth Version: 4.2
• Bluetooth Profiles: A2DP 1.3, AVRCP 1.5
• Bluetooth Frequency Range: 2402–2480MHz
• Maximum Bluetooth Transmitting Power: Less than 10dBm (EIRP)
• 5GHz Wireless Frequency Range: 5736.35–5820.35MHz
• Maximum 5GHz Transmitting Power: Less than 9dBm (EIRP)
• Modulation Types: GFSK, π/4 DQPSK, 8DPSK

USB Playback Support

• Supported File Formats: MP3, WAV
• MP3 Codecs: MPEG-1 Layer 2/3, MPEG-2 Layer 3, MPEG-2.5 Layer 3
• MP3 Sampling Rate: 16–48kHz
• MP3 Bitrate: 80–320kbps
• WAV Sampling Rate: 16–48kHz
• WAV Bitrate: Up to 3000kbps

Dimensions and Weight

Packaging Information

• Package Dimensions (W × H × D): 1045 × 310 × 405mm
• Gross Package Weight: 10.32kg

• Note: USB music playback is available in the US version only. In other versions, the USB port is intended for service use only.

Audio Output: All power ratings are maximum values measured at 1% total harmonic distortion (THD).
